PREMIUM SURVEILLANCE
CCTV CAMERAS
CCTV CAMERAS
5.0MP High resolution
S+265 compression, min bandwidth 2Mpbs
SMD IR, Brightness enhance 25%
Cable free/Reset button, TF Slot, IP67, Face Detection
Product Carousel Tabs
Alarms, Detectors
HX100
Pir Indoor Motion Sensor
Two infrared sensors
Microcontroller signal processing
Pet Immune up to 25kg
Sensitivity adjustment
N.O. & N.C. relays switched optionally
Anti-tamper switch
Temperature compensation
High RFI/EMI immunity
Detection range: up to 12m (39ft)
Dimension:135*70*50mm
SKU: n/a
Alarms, Detectors
HX1000
Waterproof UV proof Pet immunity outdoor PIR motion sensor detector dual Sensor
Provide with waterproof to be suitable for outdoor usage
Dual sensors Pet immunity Detector
Adopt microprocessor
Special filter lens, white light immunity 10000Lux
Bug guard
Wide angle lens and curtain lens optional for different locale
Temperature auto-compensation to adapt environment change
Alarm output N.C/N.O optional to adapt different alarm system
Pet (<20kg) immunity
BK-100 wall mount bracket available separately
SKU: HX1000
Alarms, Detectors
HX80HDF
Digital Photo Beam Sensor
Detection range: outdoor 40m & 80m .With selectable 8-channel beam frequencies .
Powerful and reliable twin beam detector .
Easy optical alignment with LED indication .
Adjustable beam interruption period(50~700msec) .
Form C relay providing more applications .
Up to 8-sets for multiple installation .
Anti-Forest design
Lighting & surge protection, Automantic gain control circuit.
Target yellow color, tuned to the peak wavelength of human vision,to be easily targeted in the beam alignment
SKU: Hx80hdf
CCTV, DVR's
ADVR7008T-MH-E
8CH 5 in 1 1080P DVR
Support 8ch Unreal-time Encoding
Support AHD/TVI/CVI/CVBS/IP Self-adaptive
HDMI/VGA Simultaneous Video Output
Support DHCP,FTP,DNS,DDNS,NTP,UPNP,EMAIL,3G,WIFI
Support ONVIF Protocol
Support WEB,VMS,MYEYE Platform
Support Mobile Phone Monitoring(IOS ,Android)
Cloud Services,P2P,Alarm Information Push To Phone
Support Multi-Language
SKU: ADVR7008T-MH-E
CCTV, DVR's
ADVR7804T-LM-E
4CH 5 in 1 1080N DVR
Support 4ch/8ch Unreal-time Encoding
Support AHD/TVI/CVI/CVBS/IP Self-adaptive
HDMI/VGA Simultaneous Video Output
Support DHCP,FTP,DNS,DDNS,NTP,UPNP,EMAIL,3G,WIFI
Support ONVIF Protocol
Support WEB,VMS,MYEYE Platform
Support Mobile Phone Monitoring(IOS ,Android)
Cloud Services,P2P,Alarm Information Push To Phone
Support Multi-Language
SKU: ADVR7804T-LM-E
CCTV, DVR's
DVR116GF1
HILOOK DVR 16CH 1080P Lite 1HD
Turbo HD DVR
Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Long distance transmission over UTP and coaxial cable
One-key enable H.264 compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports 1080p lite and when enabled, the image effect is similar with 1080p
Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution
One SATA interface (up to 6 TB capacity per HDD)
Smart search for efficient playback
SKU: DVR116GF1
CCTV, DVR's
DVR208GF1
HILOOK DVR 8CH 1080P 1HDD
Turbo HD DVR
Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Long distance transmission over UTP and coaxial cable
One-key enable H.264 compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports real-time 1080p lite and when enabled, the image effect is similar with 1080p
HDMI/VGA output at up to 1920 × 1080 resolution
One SATA interface (up to 6 TB capacity per HDD)
4/8/16-ch synchronous playback
Smart search for efficient playback
SKU: DVR208GF1
CCTV, DVR's
DVR208UF1
HILOOK DVR 8CH 5MP TVI 1HDD
Turbo HD DVR
Video Input and Transmission
l Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
l Up to 8/16-ch 8 MP IP cameras input for DVR-204/208U-K1
l 8 MP/5 MP/4 MP HDTVI video input and live view for DVR-208U-K1, and 5 MP/4 MP for DVR-204U-K1
l Defogging function enabled for the supported analog cameras
l Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression and Recording
l H.265 Pro /H.265 Pro/H.265/H.264 /H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
l Connectable to H.265 /H.265/H.264 /H.264 IP cameras
l H.265 can be enabled to improve encoding efficiency and reduce data storage costs
l Full channel recording at up to 8 MP resolution
Video Output
l Simultaneous HDMI/VGA output
l HDMI output at up to 4K (3840 × 2160) resolution for DVR-208U-K1
Storage and Playback
l 1 SATA interface (up to 10 TB capacity per HDD)
l 4/8-ch synchronous playback
l Smart search for efficient playback
l Supports the 3rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
Smart Function
l Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
l Supports line crossing detection and intrusion detection of all channels, and 2-ch sudden scene change detection
l VCA information overlay in live view and smart playback
l VQD (Video Quality Diagnostics)
Network & Ethernet Access
l Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
l 1 RJ45 10M/100M self-adaptive Ethernet interface for DVR-204U-K1, and 1 RJ45 10M/100M/1000M self-adaptive Ethernet interface for DVR-208U-K1
l Output bandwidth limit configurable
SKU: DVR208UF1
CCTV, DVR's
DVR216QF1
HILOOK DVR 16CH 1080P 1HDD
Turbo HD DVR
Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Long distance transmission over UTP and coaxial cable
One-key enable H.264 compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports 1080p lite and when enabled, the image effect is similar with 1080p
Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution
One SATA interface (up to 6 TB capacity per HDD)
Smart search for efficient playback
SKU: DVR216QF1
CCTV, DVR's
DVR216UF2
HILOOK DVR 16CH 5MP TVI 2HDD
Turbo HD DVR
Video Input and Transmission
l Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
l Up to 8/16-ch 8 MP IP cameras input for DVR-204/208U-K1
l 8 MP/5 MP/4 MP HDTVI video input and live view for DVR-208U-K1, and 5 MP/4 MP for DVR-204U-K1
l Defogging function enabled for the supported analog cameras
l Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression and Recording
l H.265 Pro /H.265 Pro/H.265/H.264 /H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
l Connectable to H.265 /H.265/H.264 /H.264 IP cameras
l H.265 can be enabled to improve encoding efficiency and reduce data storage costs
l Full channel recording at up to 8 MP resolution
Video Output
l Simultaneous HDMI/VGA output
l HDMI output at up to 4K (3840 × 2160) resolution for DVR-208U-K1
Storage and Playback
l 1 SATA interface (up to 10 TB capacity per HDD)
l 4/8-ch synchronous playback
l Smart search for efficient playback
l Supports the 3rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
Smart Function
l Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
l Supports line crossing detection and intrusion detection of all channels, and 2-ch sudden scene change detection
l VCA information overlay in live view and smart playback
l VQD (Video Quality Diagnostics)
Network & Ethernet Access
l Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
l 1 RJ45 10M/100M self-adaptive Ethernet interface for DVR-204U-K1, and 1 RJ45 10M/100M/1000M self-adaptive Ethernet interface for DVR-208U-K1
l Output bandwidth limit configurable
SKU: DVR216UF2
CCTV, NVR's
TC-NR5020M7-S4
20ch 4K S 265 NVR
20-ch 4K/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF IP Camera Input
4-ch 4K/16-ch 1080P/20-ch 720P/4CIF Realtime Display
20-ch Sub-stream 4CIF Realtime Display
4-ch 4K/16-ch 1080P/720P/4CIF Sync Playback
Up to 4K Resolution Recording
Bandwidth in/out 400Mbps/200Mbps
HDD Quota and Group Management
Dual Gigabit Network Interfaces
Support 20-ch Intelligent Analysis Process
Smart Search&Recording, Plug&Play
Support ANR Funtion
Support N M Hot Standby Function
1x HDMI, 1x VGA, Same Video Source, Max Resolution 4K
4 SATA(Up to 32TB), Alarm I/O 16/4, Audio I/O 1/1, 2x USB
CE, FCC
SKU: TC-NR5020M7-S4
CCTV, Dome Cams
TC-NCL522S
1/2.8 Inch 5MP CMOS Sensor
2.8mm Fixed Lens, ICR Switch
10m～15m IR
Triple Stream, with Mainstream 2592×1944
Support WDR, BLC,HLC, DNR and Image Flip
Support Compression H.265,H.264 HP/MP/BP,M-JPEG Coding, and S Super Stream
Character Superposition with Character Library including Vector and Lattice Options
VCA including 8 Behavior Analytics, Video Abnormal Detection, Facial Recognition and People Counting
Support Corridor Model, Smart Defog and Scene Model
SKU: TC-NCL522S
CCTV, Speed Domes
TC-NH3204IE
H.265 2MP 4x Starlight Mini EW IR POE PTZ
H.265 compression
Early Warning(EW)
IR LED White Light Speaker
Starlight Ultra Low Light 0.002lux
Up to 1920×1080@30fps
Mechanical WDR 140dB
Min. Illumination Color: 0.002 Lux, B/W: 0.001 Lux, 0 Lux with IR
VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Early warning/Crowd/Audio Abnormal Detection/Video Abnormal Detection
Smart IR, IR Range: 50m
Speed Max 60°/s, -2~90° Tilt Angle
Optical Zoom: 4x, Digital Zoom: 16x
Built-in Gyro and Support Image Auto-flip
Audio in ： Bulit-in Mic/1 ch Line, Audio out：Built-in Speaker/1- ch , Alarm in/out 2/1,MicroSD Card Slot, up to 128GB, Reset Button,RS485
Support Wifi
Operating Conditions -10°C-50°C, 0～95% RHG
TVS 6000V, Lightning/Surge 4000V Protection, Indoor IP65
CE, FCC
SKU: TC-NH3204IE
Home Entertainment
Product Spotlight
Super Starlight Ultra Low Light
- Super Starlight Ultra Low Light 0.0004lux
- Up To 1080P, 1920×1080@30fps
- S+265、H.265/H.264 HP/MP/BP/M-JPEG Codec
- Support perimeter alert and tripwire alert，Person-vehicle separation
- “VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
Lost/Running/Loitering/Parking/Early Warning/Crowd/People counting/Face detection/Audio Abnormal Detection/Video Abnormal Detection” - Support P2P ,the APP support setting up alert，alert plan and line drawing, uploading customized alert sounds
- Mechanical WDR 140dB
- NIR, WDR, 3D DNR, HLC, Dual-ICR, AWB, AGC
- Interface Built-in Speaker&mic,Audio in/out 1/1,Alarm in/out 1/0, MicroSD Card Slot, up to 128GB, USB Storage up to 128GB ,Reset Button
- TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67
- Operating Conditions -35℃～65℃, 0～95% RHG
- CE, FCC
